Thermal Break
Sliding Door System
Slim-frame thermal break sliding doors for large openings, heat insulation and dust protection.
Slim
Frame
Large
Opening
Heat & Dust
Protection
Smooth
Sliding
Technical Specifications
Product Type
Thermal Break Sliding Door System
Series
ES152 / ES170
Glass Options
Double / Triple Insulated Glass
Opening Type
Sliding / Lift & Slide Option
Track Options
2 Track / 3 Track
Panel Load
400kg+ Panel Load Option
Sealing System
Multi-sealing Structure
Application
Villas, Terraces, Hotels, Resorts
Available Series
Choose the suitable series according to opening size,performance requirements and project budget.
ES152
Sliding Door System
Main series for villa terraces and large openings.
- 400kg+ Panel Load
- Multi-track Options
- Slim Interlock Option
ES170 High-End
Sliding Door System
Premium series for large panels and higher thermal performance.
- 400kg+ Panel Load
- Better Thermal Performance
- Multi-sealing Design
Related systems: Wide Opening Folding Doors · Slim Frame Panoramic Windows · Motorized Smart Pergola
Series Comparison
Item
ES152 Sliding Door System
ES170 High-End Sliding Door System
Positioning
Main Series
Premium Series
Thermal Insulation
Grade 8
Grade 9
Sound Insulation
Grade 3
Grade 3
Water Tightness
Grade 5
Grade 6
Air Tightness
Grade 8
Grade 8
Wind Pressure Resistance
Grade 9
Grade 9
Best For
Villas, Terraces
Luxury Villas, Hotels
Series Comparison
Positioning
ES152: Main Series
ES170: Premium Series
Thermal Insulation
ES152: Grade 8
ES170: Grade 9
Sound Insulation
ES152: Grade 3
ES170: Grade 3
Water Tightness
ES152: Grade 5
ES170: Grade 6
Air Tightness
ES152: Grade 8
ES170: Grade 8
Wind Pressure Resistance
